Bug Report: Tagged VLAN traffic has PCP/CoS field set to 5

Reference: https://en.wikipedia.org/wiki/IEEE_802.1Q. The PCP field is also known as priority / class-of-service.This is happening on all tagged VLAN traffic, including ARP packets. I tried two switches: an ICX 6450 and an ICX 7250.Using `ip pcp-remark 0` on the VE interface corrects all traffic except ARP.This is a very strange behavior -- possibly a bug? Can someone else confirm this?

R500 Firmware, Can't find that matches Zone Director

I have a network running Zone Director 3000 on firmware 9.12.3.0 build 166. I have 27 R500 access points working fine.I have two R500 on 104.0.0.0.1347.bl7 that i cannot get past being a Rogue AP showing as "Island"I'm not sure how to get these to correct firmware and join the ZD. I've reset them countless times, tried numerous things including the aforementioned firmware someone said should get them to join and upgrade

Configuring 3 SSIDs with 3 different VLANS and getting DHCP on those VLANS for clients connected.

Background :We currently used a ZoneDirector 1200 with 8 R650 AP all on a flat network. (No VLANS)We bought a Virtual Smart Zone (runningfirmware version 7.1.0000) and 8 R750 AP.Our current setup looks like this :Fortigate Firewall FG101 running version 6.2 firmware with three VLANS - VLAN 10-OT(172.16.x.1/255.255.255.0)VLAN 20-Corporate (192.168.x.1/255.255.255.0) and VLAN 100- BYOD (10.10.X.1/255.255.255.0). Fortigate runs DHCP for VLAN 10 and VLAN 100 while Windows server runs DHCP for VLAN 20 which is the current LAN (cable switch).There is a trunk configured between the fortigate and the FortiSwitch.Fortigate Switch 224E POE : also running the same VLANS as the fortigate and have a few ports dedicated to VLAN 10, VLAN 20 and VLAN 100. All receiving DHCP on all VLANS. I intend to put all 8 AP on this forti switch.DHCP Config for VLAN 20 - gateway: 192.168.x.1 , DHCP Server : 192.168.X.150 (a windows server VM), DNS :192.168.X.150DHCP Config for Vlan 10 - gateway : 172.16.X.1 , DHCP Server:172.16.X.1, DNS ::192.168.X.150DHCP Config for Vlan 100 - gateway : 10.10.x.1, DHCP Server : 10.10.X.1,DNS ::192.168.X.150What am trying to achieve.Am trying to get a scenario whereby I have 3 VLANs -VLAN 20 Corporate - Clients on this SSID will recieive DHCP address from the windows server in this subnet. But will need to authenticated VIA Active directory username and password.VLAN10 OT - Clients connecting to this SSID will recive DHCP address from the Firewall DHCP in this subnet. Only requires a passphraseVLAN100 - Clients connecting to this SSID will recive DHCP address from the Firewall DHCP in this subnet. Only requires a passphrase.Current work done :Ive installed the Virtual Smart Zone and AP are online. Virtual Smart Zone is on VLAN 20 and has an ip of192.168.x.254/255.255.255.0However , I need 3 SSIDs based on the VLANs 10,20,100 networks.Once a client connect to the SSID, they should hit the DHCP for the respective VLAN associated with the SSID just like it works when on LAN.How can I go about this , am fairly new to Ruckus configuration.Thanks and happy to provide more information that can assist.If you are able to i wouldnt mind to get more information about the following details:How do I associate the VLAN with the SSID?How will the DHCP get to the client on each SSID?Is there a need to configure a port settings on the fortiswitch ?How does the traffic travel between DHCP, Virtual Smart Zone and the Clients connecting to the AP.

ICX 7250 FIPS Firmware Sig Setup Issues

Aloha,This is our first time testing Ruckus products, and we've encountered an issue while configuring FIPS mode. I believe that the SIG files were not copied to the switch during the09.0.10j_cd8 update. I'm now experiencing a boot loop, and haven't yet managed to resolve it. Attempted TFTP image transfer from the bootloader, and mounting the files from a USB with the manifest file, no luck.If there is a technical guide for recovery in this scenario that I've overlooked, please direct me to it. From my understanding, this switch was not purchased new/through an authorized channel, so I do not believe it has any warranty or technical support coverage.Thanks!Ruckus Networks Bootloader: 10.1.27T215 (Feb 06 2025 - 20:29:34)

ICX-7450 limited to 08.0.80f - can't upgrade!

I've tried countless times to get my ICX-7450 past 08.0.80f without successChat GPT is trying to tell me my A0 ASIC is limiting things, the BCM56548_A0but googling doesn't confirm thisI get kernel panics for all UFI images, and even non UFI past08.0.80fany tricks? I need some features from 08.0.90d and up, specifically the 40G breakout capability (chat GPT tells me this is the earliest revision supporting)
